Plot Stock Recruit Relationship

Plot Stock Recruit Relationship

plot_stock_recruitment(
  dat,
  spawning_biomass_label = "mt",
  recruitment_label = "mt",
  interactive = TRUE,
  era = NULL,
  module = NULL,
  scale_amount = 1,
  make_rda = FALSE,
  figures_dir = getwd()
)

Arguments

dat

Data frame or list. A tibble or named list of tibbles (input as list()) returned from convert_output.

If inputting a list of tibbles, the first tibble's reference point defined in ref_line is used to plot a reference line or calculate relative spawning biomass.

spawning_biomass_label

String. Units for spawning biomass

Default: "mt"

recruitment_label

String. Units for recruitment

Default: "mt"

interactive

Logical. TRUE/FALSE; indicate whether the environment the plot is being made in is interactive. By default, this is set to false. If true, dependent on your data, a option menu will pop-up.

Default: TRUE

era

String. Era of data.

Default: "time"

Options: "early", "time", "fore" (forecast), or NULL (all data)

module

Character vector. (Optional) Module name found in dat$module_name. If selecting >1 module, place them in a vector like c("module1", "module2").

Default: NULL

If the interactive and >1 module_name is found, user will select the module_name in the console. @seealso filter_data()

scale_amount

Number. A number to scale the y-axis values.

Default: 1

make_rda

Logical. TRUE/FALSE; indicate whether to save the object and make an automated caption and alternative text in the form of an rda object. If TRUE, the rda will be exported to the folder indicated in the argument "figures_dir".

Default: FALSE.

figures_dir

Path. Path to the "figures" folder.

Default: getwd()

The folder is created within the path if it does not exist.

Value

A plot showing the stock recruitment relationship.

Details

The input is from an assessment model output file translated to a standardized output (convert_output). There are options to return a ggplot2 object or export an .rda object containing associated caption and alternative text for the figure.

See also

convert_output(), filter_data(), process_data(), plot_timeseries(), export_kqs(), insert_kqs(), create_rda()

Examples

plot_stock_recruitment(
  dat = stockplotr:::example_data,
  interactive = FALSE,
  spawning_biomass_label = "metric tons",
  recruitment_label = "metric tons",
  module = "DERIVED_QUANTITIES"
)
#> Scale for x is already present.
#> Adding another scale for x, which will replace the existing scale.
#> Scale for x is already present.
#> Adding another scale for x, which will replace the existing scale.
